Tapping Machines - Manual Feed
1st Generation - Sutaible for production of 7000 to 12000 components per month.
Features under this category
- Manually operated Machines.
- Highly Versatile & Reliable Machines for production.
- Easy to operate and maintenance free.
- Featured with high accuracy, high rigidity, low noise & wide range of speed change.
- Rigid stream lined construction with reliable & lasting accuracy.
- Machines plug to start type.
- Combines Tapping & Drilling functions on one unit, Hence suitable for batch type production.
- Single point graduated collar depth control system is provided for max operator convenience.
- Ex-stock availability & competitive pricing.
- Spares available on demand.
- Machine also available in Fabricated Stand Models.
| Manual Feed Electrical Drilling & Tapping Machine | |||||
| Model | LGT - 550A | LGT - 550B | LGT - 340A | LGT - 340B | |
| Maximum Drilling Capacity(S45C) | Ø 25mm | Ø 20mm | Ø 16mm | Ø 13mm | |
| Maximum Tapping Capacity(S45C) | M20 | M16 | M12 | M10 | |
| Spindle Taper | MT3 | MT3 | MT2 | MT2 | |
| Spindle Travel | 140mm | 120mm | 100mm | 80mm | |
| Spindle Speed | 150-1270 rpm | 220-1670 rpm | 170-1900 rpm | 360-1560 rpm | |
| Number of Speed | 9 | 9 | 9 | 4 | |
| Throat (Coloum to spindle centre) | 230mm | 230mm | 180mm | 180mm | |
| Column Diameter | Ø 102mm | Ø 92mm | Ø 80mm | Ø 80mm | |
| Table Diameter | 420mm | 400mm | 360mm | 360mm | |
| Base Size | 380 * 600mm | 335 * 580 | 300 * 500mm | 300 * 500 | |
| Distance From Spindle To Table | 630mm | 720mm | 450mm | 450mm | |
| Distance From Spindle To Base | 930mm | 920mm | 620mm | 620mm | |
| Motor HP | 2HP | 1.5HP | 1HP | 0.5HP | |
| Overall Height | 1540mm | 1500mm | 1070mm | 1070mm | |
| Weight | 190kg | 140kg | 90kg | 75kg | |
Standard Accessories
- Comprehensive electrical control panel with selector switch for drilling & tapping operations without spindle motor protection.
- Instruction manual.
- V belts.
- Intermediate table with rack & pinion arrangement for lifting & lowering of work table.
- Main motor of reputed brand, 3 phase, 50 Hz, 6 pole, S1 duty.
Optional Accessories
- Tool Holders
- Coolant system consisting of:- Reservoir tank with chip collection tray, separation baffles, coolant pump with 3 phases induction motor, flexible piping & fittings, on/off valves, splash guards or chip collection tray etc.
- Machine lamp Arrangement.
- Square Work Table.
